Sumitomo DEMAG IntElect 2 350/830-2200
High-performance 3500 kN injection molding machine with integrated SEPRO robotic system and MuCell technology. Features 60mm screw diameter, 891 cm³ max injection volume, and advanced automation capabilities. Excellent condition with only 5,290 working hours.
Key Specifications
- Robot Model: SEPRO 5T35 2000/900/TE-1800
- Material Hopper Capacity: 110 ltr
- Conveyor Load Capacity: 38 kg/m²
- Screw Diameter: 60 mm
- Platen Size Height: 1168 mm
Complete Specifications
| Clamping Force | 3500 kN 357 Ton |
| Max Holding Force | 3850 kN |
| Opening Width | 725 mm |
| Screw Diameter | 60 mm |
| Tool Installation Height Min | 400 mm |
| Tool Installation Height Max | 900 mm |
| Platen Size Height | 1168 mm |
| Platen Size Width | 1144 mm |
| Tie Bar Spacing Width | 830 mm |
| Tie Bar Spacing Height | 830 mm |
| Tool Weight Max | 6600 kg |
| Movable Tool Weight Max | 3800 kg |
| Fixed Tool Weight Max | 5100 kg |
| Ejector Force | 250 mm |
| Increased Ejector Force | 100 kN |
| Max Ejector Speed | 270 mm |
| Spray Pressure | 2426 bar |
| Max Injection Volume | 891 cm³ |
| Max Injection Speed | 160 mm/s |
| Max Dosing Path | 315 mm |
| Max Nozzle Path | 520 mm |
| Nozzle Immersion Depth | 20 mm |
| Cylinder Heater Power | 23.1 kW |
| Material Hopper Capacity | 110 ltr |
| Robot Model | SEPRO 5T35 2000/900/TE-1800 |
| Robot Stroke | 2000 mm |
| Robot Speed | 3.5 m/s |
| Robot Horizontal Demolding Stroke | 900 mm |
| Robot Vertical Demolding Stroke | 1800 mm |
| Robot Weight | 583 kg |
| Robot Axis Rotation | 0° – 90° pneumatic |
| Conveyor Width | 870 mm |
| Conveyor Usable Width | 800 mm |
| Conveyor Length | 3500 mm |
| Conveyor Height Min | 880 mm |
| Conveyor Height Max | 1220 mm |
| Conveyor Load Capacity | 38 kg/m² |
| Conveyor Belt Speed | 5.7 m/min |
| Conveyor Frames | 2 |
| Conveyor Tunnel Height | 500 mm |
| Working Hours | 5290 hours |
