SML MiniCast 1500
High-performance 5-layer stretch film extrusion line capable of producing up to 905 kg/hour with advanced automation and precision control. Features multiple extruders, automatic die control, and integrated winding system for professional stretch wrap film manufacturing.
Key Specifications
- Extruder A Model: SML-ES-90/33
- Extruder Bcd Model: SML-ES-60/28
- Winder Model: Cast Film Turret Winder Series W4000
- Extruder A Max Output Lldpe: 800 kg/h
- Extruder Bcd Max Output Lldpe: 200 kg/h each
Complete Specifications
| Number Of Extruders | 5 |
| Layer Distribution | B/A/D/A/C (10/35/10/35/10%) |
| Extruder A Model | SML-ES-90/33 |
| Extruder A Ld Ratio | 90/33 |
| Extruder A Max Output Lldpe | 800 kg/h |
| Extruder Bcd Model | SML-ES-60/28 |
| Extruder Bcd Ld Ratio | 60/28 |
| Extruder Bcd Max Output Lldpe | 200 kg/h each |
| Materials Processed | LLDPE, VLDPE |
| Material Mfi Lldpe | 2.8–5.0 g/10min (190°C/2.16kg) |
| Material Mfi Vldpe | 2.8–5.0 g/10min (190°C/2.16kg) |
| Die Type | Flat die, automatic with control |
| Die Width | 2,050 mm |
| Lips Width | 2.050 mm |
| Roll Width | 2.100 mm |
| Web Width | 1.500 mm |
| Lip Gaps Adjustable | 10–45 μm |
| Final Film Widths | 3x500mm, 6x250mm, 3x400mm, 2x750mm |
| Max Output 15 Micron | 745 kg/h |
| Max Output 17 Micron | 845 kg/h |
| Max Output 23 Micron | 905 kg/h |
| Chill Roller Width | 2.100 mm |
| Chill Roller Diameter | 1.600 mm |
| Winder Model | Cast Film Turret Winder Series W4000 |
| Winder Max Line Speed | 650 m/min |
| Winder Max Reel Diameter | 400 mm |
| Winder Winding Width | 3×500 mm |
| Winder Number Of Turrets | 1 |
| Winder Number Of Shafts | 4 |
| Winder Shaft Diameter | 3 inch |
| Winder Min Diameter | 82 mm |
| Winding Tension | 15–100 N/m |
| Contact Pressure | 50–500 N |
| Cycle Time | 20–25 s |
| Feedblock | Cloeren 5-layer/3-up |
| Vacuum Box | Triple-chamber SML-TC/2050mm |
| Casting Section | SML-CS/2100/650 |
| Thickness Measurement | X-ray sensor |
| Edge Pinning | Electrostatic |
| Screen Changer A | SML-MF-man/90 (manually operated) |
| Screen Changer Bcd | SML-MF-man/60 (manually operated) |
| Control System | SML Automatic Control System SML-CS-2/SMILE/4 |
| Data Logging | SMILE Process Analyzer |
| Chiller | Frigosystem |
| Compressor | MSD V 30-37 |
