KRAUSS MAFFEI KM 2000-17200 MX Injection Moulding Machine
KRAUSS MAFFEI KM 2000-17200 MX Injection Moulding Machine
KRAUSS MAFFEI KM 2000-17200 MX Injection Moulding Machine is an industrial-grade injection moulding machine with 200 kN clamping force and integrated robotic arm system. Features advanced sequential injection molding with 12 hydraulic channels and comprehensive mold heating capabilities for high-precision plastic component manufacturing.
Key Specifications
- Cylinder Type: 17.200 MC
- Robot Type: S900II-BB
- Injection Capacity: 17,200 cm³
- Oil Tank Capacity: 2,500 liters
- Cylinder Diameter: 135 mm
Complete Specifications
| Machine Type | Injection Moulding Machine |
| Clamping Force | 200 kN (200 T) |
| Injection Capacity | 17,200 cm³ |
| Max Injectable Mass | 8,792 cm³ |
| Max Injection Pressure | 1,789 bar |
| Cylinder Type | 17.200 MC |
| Cylinder Diameter | 135 mm |
| Max Cylinder Temperature | 375°C |
| Injection Unit Thermoregulation Zones | 7 |
| Heating Power Per Zone | 2×8 100W |
| Mold Heating Power | 122 kW |
| Mold Heating Zones | 48 |
| Centering Ring Diameter | 315 mm |
| Min Mold Height | 1,000 mm |
| Max Mold Height | 1,700 mm |
| Max Clamping Plate Spacing | 3,600 mm |
| Horizontal Bright Opening | 1,800 mm |
| Vertical Bright Opening | 1,500 mm |
| Clamping Plate Horizontal Dimension | 2,580 mm |
| Clamping Plate Vertical Dimension | 2,270 mm |
| Max Tool Weight | 50,000 kg |
| Cores Fixed Side | 2 |
| Cores Movable Side | 3 |
| Air Ejection Movable Side | YES (2 units) |
| Air Ejection Stationary Side | YES (1 unit) |
| Hydraulic Ejector | Defective |
| Sequential Injection Molding | Hydraulic |
| Sequential Control Channels | 12 |
| Rack Control For Sequential Molding | YES |
| Electric Motor Power | 160 kW |
| Motor Speed | 1,420 rpm |
| Oil Tank Capacity | 2,500 liters |
| Machine Mass Oil Free | 137,000 kg |
| Working Hours Uptime | 7,989 hours |
| Working Hours Cycle Time | 85,136 hours |
| Robot Type | S900II-BB |
| Robot Arms | 1 |
| Robot Disposal Position | Lateral |
| Tip Thread Injector Cylinder | M56x3 |
| Max Cochlear Revolutions | 245 g/s |
Interested in this equipment?
Contact us for pricing, availability, and additional information.How do I find the price of this machine?
We are happy to provide you the price for the machine you’re interested in via email. Please use the contact form down below or email us at info@euro-machinery.com. Mention the machine reference number and one of our team members will reach out to you shortly.
Where is the machine located?
Most of our machines are located in Europe, but for specific details on this machine please contact us.
How do I buy a machine?
Send us an inquiry on the machine product page via the contact form and one of our sales managers will get in touch with you shortly. If you need help finding the right machine, please send us an email or call – we are happy to help you. Find more information about how to buy used machines down below.
How does transport work?
Transport is a case by case basis and depends on the size and distance a machine should travel. We work together with the buyer and seller to facilitate transport when a machine is being bought. We have many partners for transport and can help find a supplier to suit your needs.
