Ref: 130075

ILLIG RV53 Pressure Vacuum Thermoforming Machine

Brand
Forming area500 x 350 mm

Find similar machines

ILLIG RV53 Pressure Vacuum Thermoforming Machine

Share this machine

Professional-grade ILLIG RV53 thermoforming machine designed for PE/PP material processing with roll-fed capability. Features a 500 x 350 mm forming area and 100 mm forming depth, ideal for high-volume production applications.

Key Specifications

  • Model: RV53
  • Machine Type: Pressure Vacuum Thermoforming
  • Material Thickness Min: 0.10 mm
  • Material Thickness Max: 1.3 mm
  • Forming Area: 500 x 350 mm

Complete Specifications

Machine Type Pressure Vacuum Thermoforming
Brand ILLIG
Model RV53
Materials Compatible PE/PP
Material Thickness Min 0.10 mm
Material Thickness Max 1.3 mm
Feeding System Roll fed
Forming Area 500 x 350 mm
Forming Depth 100 mm
Stacking Unit Yes
Orientation Horizontal
Condition Remarks In good working condition

Interested in this equipment?

Contact us for pricing, availability, and additional information.
The ILLIG RV53 is a horizontal pressure vacuum thermoforming machine engineered for efficient processing of polyethylene (PE) and polypropylene (PP) materials. This machine accommodates material thickness ranging from 0.10 mm to 1.3 mm, making it versatile for various thermoforming applications. The forming area measures 500 x 350 mm with a maximum forming depth of 100 mm, providing substantial capacity for complex part geometries. Equipped with roll-fed material feeding system and an integrated stacking unit, this machine streamlines production workflows and enhances operational efficiency. The horizontal configuration allows for optimal material handling and part removal. Currently in good working condition and available for inspection with video documentation available upon request.

Professional-grade ILLIG RV53 thermoforming machine designed for PE/PP material processing with roll-fed capability. Features a 500 x 350 mm forming area and 100 mm forming depth, ideal for high-volume production applications.

Key Specifications

  • Model: RV53
  • Machine Type: Pressure Vacuum Thermoforming
  • Material Thickness Min: 0.10 mm
  • Material Thickness Max: 1.3 mm
  • Forming Area: 500 x 350 mm

Complete Specifications

Machine Type Pressure Vacuum Thermoforming
Brand ILLIG
Model RV53
Materials Compatible PE/PP
Material Thickness Min 0.10 mm
Material Thickness Max 1.3 mm
Feeding System Roll fed
Forming Area 500 x 350 mm
Forming Depth 100 mm
Stacking Unit Yes
Orientation Horizontal
Condition Remarks In good working condition

Interested in this equipment?

Contact us for pricing, availability, and additional information.
The ILLIG RV53 is a horizontal pressure vacuum thermoforming machine engineered for efficient processing of polyethylene (PE) and polypropylene (PP) materials. This machine accommodates material thickness ranging from 0.10 mm to 1.3 mm, making it versatile for various thermoforming applications. The forming area measures 500 x 350 mm with a maximum forming depth of 100 mm, providing substantial capacity for complex part geometries. Equipped with roll-fed material feeding system and an integrated stacking unit, this machine streamlines production workflows and enhances operational efficiency. The horizontal configuration allows for optimal material handling and part removal. Currently in good working condition and available for inspection with video documentation available upon request.
  • I would like to know the price of this machine
We are happy to provide you the price, please use the contact form or email us and mention the reference number of this machine.
  • Where is the machine located?
Most of our machines are located in Europe, but for specific details on this machine please contact us.
