ILLIG RDK54 Pressure Vacuum Thermoforming Machine
Professional-grade ILLIG RDK54 thermoforming machine designed for PE/PP material processing with pneumatic roll feed and dual-action forming capabilities. Features a maximum forming area of 500 x 380 mm with precise material transport accuracy and is currently in good working condition.
Key Specifications
- Machine Type: Pressure Vacuum Thermoforming
- Unwinding Type: Pneumatic
- Material Width Max: 610 mm
- Material Width Min: 200 mm
- Material Thickness Max: 1.70 mm
Complete Specifications
| Machine Type | Pressure Vacuum Thermoforming |
| Materials Processed | PE/PP |
| Machine Feeding | Roll feed |
| Unwinding Type | Pneumatic |
| Max Forming Area | 500 x 380 mm |
| Material Width Max | 610 mm |
| Material Width Min | 200 mm |
| Material Thickness Max | 1.70 mm |
| Material Thickness Min | 0.25 mm |
| Material Transport Accuracy | ±0.2 mm |
| Index Length Max | 418 mm |
| Index Length Min | 150 mm |
| Depth Of Draw Positive | 120 mm |
| Depth Of Draw Negative | 120 mm |
| Mould Closing Force | 50 kN |
| Forming Pressure | 6 bar |
| Max Cycles | 40 per minute |
Interested in this equipment?
Contact us for pricing, availability, and additional information.How do I find the price of this machine?
We are happy to provide you the price for the machine you’re interested in via email. Please use the contact form down below or email us at info@euro-machinery.com. Mention the machine reference number and one of our team members will reach out to you shortly.
Where is the machine located?
Most of our machines are located in Europe, but for specific details on this machine please contact us.
How do I buy a machine?
Send us an inquiry on the machine product page via the contact form and one of our sales managers will get in touch with you shortly. If you need help finding the right machine, please send us an email or call – we are happy to help you. Find more information about how to buy used machines down below.
How does transport work?
Transport is a case by case basis and depends on the size and distance a machine should travel. We work together with the buyer and seller to facilitate transport when a machine is being bought. We have many partners for transport and can help find a supplier to suit your needs.
