DGM Smartfold 1100 High Speed Automatic Folder Gluer
DGM Smartfold 1100 High Speed Automatic Folder Gluer
DGM engineered the Smartfold 1100 premium automatic folder gluer for the most demanding packaging companies, commercial printers, and finishers. This state-of-the-art machine handles small to large sized boxes with flexible operation and advanced servo motor technology, capable of processing up to 400 m/min.
Key Specifications
- Model: Smartfold 1100
- Air Compressor Capacity: 10 m³/h
- Air Tank Capacity: 60 L
- Corrugated Flute Types: N, E & F
- Max Speed: 400 m/min
Complete Specifications
| Brand | DGM |
| Model | Smartfold 1100 |
| Reference Number | 1600010 |
| Processed Materials | Paper, Carton Board, Corrugated Board |
| Carton Board Max | 800 g/m² |
| Corrugated Flute Types | N, E & F |
| Max Speed | 400 m/min |
| Inching Speed | 20 m/min |
| Max Folded Box Thickness | 12 mm |
| Blank Width | 1100 mm |
| Length Pc | 15.92 m |
| Length Sl | 15.92 m |
| Width Pc | 1.83 m |
| Width Sl | 1.86 m |
| Height Pc | 1.4 m |
| Height Sl | 1.4 m |
| Weight Pc | 7.8 Ton |
| Weight Sl | 8 Ton |
| Electrical Connected Load Pc | 22 kW |
| Electrical Connected Load Sl | 28 kW |
| Compressed Air Pressure | 6 bar |
| Air Compressor Capacity | 10 m³/h |
| Air Tank Capacity | 60 L |
| Press Section Total Length | 5.59 meters |
| Press Section Effective Pressure Length | 3.1 meters |
| Feeder Belts | 8 |
| Front Feed Knives | 3 |
| Outer Folding Belts Adjustment | up to 180° |
| Glue Flap Pre Folder | up to 180° |
| Third Crease Pre Folder | up to 135° |
