BOBST K5
| Brand | |
|---|---|
| Material width |
2450 mm |
Find similar machines
BOBST K5
Metallizer BOBST K5
High productivity metallizer BOBST K5 with the following features: Design innovations, improved reliability, energy saving and waste reduction, Automatic sequential control (ASC), improved winding, intuitive and easy to operate, reduced cost of ownership. Brand & Model: BOBST K5 Type: Vacuum thermal evaporation with ALU Type of production: BOPP 10-50 um, CPP 15-50 um, PET 8-50 um, LDPE 25-50 um, Nylon 12-50 um, UPVC 20-100 um. Web width: 2.450 mm Diameter unwinding/rewinding reels: 1.000 mm Mechanical speed: 840 m/min Winding Tension: 49-435 N, Max Drum Tension: 1291 N Inch speed: 10 m/min, in forward or reverse direction. Other details:- Unwind & Rewind Systems:
- 152 mm core
- Lay-on arms, can operate as ‘contact’ or ‘gap winding.
- Servo motors driven.
- Linear tracking to prevent telescoping.
- Contact pressure & gap distance remotely adjustable.
- Over-wind / under-wind selection.
- Auto Tension control with load-cells, carbon fibre rollers.
- +/- 100% Taper Tension control.
- Swing-over clamp, self-centring mech. expanding shafts.
- Plasma Pre-treatment system:
- Max 4 kW/mtr 40 kHZ
- Cooling drum: 595 mm dia.
- Gas wedge injection for improved heat transfer.
- 167 mm dia. post-Coating roll for web cooling.
- Chiller: auto controlled combined heating & cooling unit, Water/glycol cooling medium.
- Min. -15 C +/-1 C. 5 min. to reheat to +20 C.
- Water-cooled Drum shield for process drum protection.
- Also, adjustable edge shield for quick changing of web width.
- 6 digital AC Vector drives, operates in open or close-loop tension control.
- Aluminium Evaporators:
- works at 5 x 10-4 mbar vacuum.
- 26 nos. 150 x 30 x 10 mm Intermetallic Evaporators, resistance heated.
- 1.6-24 mm dia. 99.8% pure Al-wire.
- 10 kg wire reel capacity.
- 11-13 V, 1000 amp installed power/ evaporator.
- Stepper motor, thyristor controlled for wire feed for each evaporator.
- 2.2 O.D. +/-5% @ 700 m/min.
- 2800-3800 micro-ohms cm
- Water-cooled troughs below each evaporator for debris collection.
- Auto adjustment of Wire feed rate thru’ Closed-loop automatic Deposition Control system, non-contact multipoint deposition monitor & computerised feed-back.
- Deposition monitor measures O.D. and ohms/sq.
- Vacuum Pump sets:
- Max 5×10-4 mbar in Coating zones.
- <5 min. Pump downtime.
- For Web coating:
- 630 cu.mtr./hr Busch NC630C dry rotary Screw
- Pump: 3900 cu.mtr./hr
- Aerzen GM 2000CMC Booster
- Pump: 4 x20” 17,500 ltr/sec
- Diffusion Pumps: 200,000 ltr/sec cryogenic
- Polycold Maxcool 4000.
- For Web Winding:
- 630 cu.mtr./hr Busch NC630C dry rotary Screw Pump,
- 3900 cu.mtr./hr Aerzen GM 2000CMC Booster Pump,
- 13,000 cu.mtr./hr Aerzen GL 8000CMY Booster Pump,
- 200,000 ltr/sec cryogenic Polycold Maxcool 4000.All booster pumps are inverter controlled
- Web Viewing Cameras:
- 4 nos., to view unwinding & rewinding, Monitor Screen.
- Control System:
- Operator console touch-screen.
- Remote Diagnosis system.
- Operator System software, Siemens S7 PLC, Siemens WinCC SCADA.
- Web coating screen, with bar chart to displays deposition profile, wire feed rates & evaporator power levels.
- Web winding screen real time to display & control of all winding parameters.
- Vacuum system screen to display operation condition of vacuum pump set & vacuum performance.
- Web cooling screen to show the operation status of the chiller.
- Alarm screen for fault diagnosis display.
- Historical reports.
