Starlinger recoStar PET 165
| Brand | |
|---|---|
| Degassing |
With |
| Output |
1900 kg/h |
| Screw Diameter |
165 mm |
Find similar machines
Recycling-Extrusion line
Starlinger recoStar PET 165
Recycling line Starlinger for PET
Recycling line Starlinger RecoSTAR for PET is equipped with FIFO pre-drying and single screw extrusion. This recycling machine is approved for the production of food-contact PET regranulate. Brand & Model: Starlinger recoSTAR PET 165 HC iV+MP Material that can be processed: PET bottle flakes, washed post-consumer waste, clean (without PVC and paper, abrasive or metallic contamination), dry (max. 1.0 % surface moisture). Material pre-ground. Screw diameter: 165 mm L/D ratio: 40 L/D (24 L/D first section + 16 L/D second section) Output: Up to 1700 – 1900 kg/h, depending on the type of material and feeding rate. Degassing: Double degassing vacuum Screen changer before the Die: Double piston backflushing filter DPB1260 Material feeding system: Force feeder Extruder hopper type: Crystallizer – Extruder combination Pelletising system: Under water pelletizing UWP100cc with inline crystallisation. Closed water circle system Extruder motor: 315 kW Attachments and accessories:- Mixing silo 20m³ for pet-flakes (incl. feeding screw, hopper)
- 2x big bag unloading station incl. feeding screw for pet-flakes
- Feeding screw for hot air dryer HAD5400 incl. metal separation
- Hot air dryer HAD5400
- Exhaust air filtration for HAD5400
- 2x water condenser for separation of ambient humidity
- Feeding screw for pre-drying unit PDU11000
- Pre-drying unit PDU11000 with dried air incl. air filtration and condensate separator
- Dosing unit for liquid additives and colours LDU45 incl. mixing unit
- Extruder EXP165HC with high vacuum unit HVAC
- Vented extruder screw and barrel in resistant version
- Melt pump for 2000 kg/h PET
- Automatic water filtration for UWP100 CC
- Filling station 1000 Litre after exp incl. diverter valve and piping
- VACUUM FEEDING SYSTEM CRY/PCU <-> FILLING STATION (BUFFER SILO)
- FILLING STATION 1000L FOR CRY/PCU (BUFFER SILO) INCL. MATERIAL VENTILATION
- FEEDING SCREW (FROM UWP100CC TO PCU2500)
- POST CRYSTALLISATION UNIT PCU2500 WITH HOT AIR
- PROCESS AIR FILTRATION FOR PCU2500
- FEEDING PARTS FOR SSP ( IN CASE OF 1 X VISCOSTAR 180)
- STAND FILTER (CONDENSER) FOR VACUUM UNIT (INCL. HAND CHAIN HOIST FOR MAINENTANCE)
- VISCOSTAR 180 BASE UNIT INCL. PREHEATING, COOLING UNIT, PLATFORMS, STAIRS ETC.
- WATER HEAT EXCHANGER FOR VISCOSTAR 180 (REQUIRED FOR AMBIENT TEMPERATURE >35°C)
- METAL SEPARATION OF SSP FINAL MATERIAL
- HIGH TEMPERATURE FEEDING SYSTEM INCL. FILLING STATION 5000L FOR SSP FINAL MATERIAL
- NITROGEN UNIT
- ENERGY RECOVERY KIT ERK2400
- SURCHARGE FOR ERK2400 STAND ALONE (INCL. ADDITIONAL FEEDING SYSTEM)
- PELLET WATER COOLER PWC1500 (PELLET TEMP. <70°C)
- HIGH TEMPERATURE FEEDING SYSTEM INCL. FILLING STATION 1000L FOR SSP OFFSPEC MATERIAL
- HIGH TEMP. FEEDING SYSTEM
- MIXING SILO 20M³ FOR PET-PELLETS (40” CONTAINER EXTRA FOR TRANSPORT)
- SURCHARGE FOR BIG BAG FILLING AT MIXING SILO
