STARLINGER ADStar-KON 60
| Brand | |
|---|---|
| Type of equipment |
Valve Sack Conversion Line |
Find similar machines
STARLINGER ADStar-KON 60
Valve Sack Conversion Line
Valve Sack Conversion Line – The STARLINGER ADStar-KON 60 is an advanced automatic bag conversion machine designed to manufacture valve sacks from woven polypropylene (PP) fabric. These durable, high-quality sacks are widely used for cement, chemicals, grains, fertilizers, and other bulk materials. Brand & Model: STARLINGER ADStar-KON 60 Type: Valve Sack Conversion Machine Application: Production of high-quality valve sacks from woven PP fabric Format range:- Double-flat bag width: 350-600 mm
- Bag length: 450-910 mm
- Bottom width: 80-180 mm (Bottom width > 160mm – only for bags open on one side)
- Opened bottom width: 170-380 mm
- Bottom center dimension: 350-750 mm
- Length of tube sections: 530-1.090 mm (Length of tube sections > 1090mm – only for bags open on one side)
- Cycle length: 635 mm
- Section length 80-300 mm
- Section length for pocket valve (optional) 80-300 mm
- Web width 170-330 mm
- Section length 230-480 mm
- Web width 75-175 mm
- Production speed: (depending on the coating and material quality) With pinless transport system Max. 60 bags/min With pin transport system (optional) Max. 60 bags/min
- Tubular fabric (2.5 – 5mm PP tapes)
- Fabric weight 60-80 g/m²
- 15% PE, 85% PP coating on both sides 20-30 g/m²
- Coating adhesion Min. 2.7 N/cm
- Width tolerance ±7 mm
- Weight tolerance (fabric with coating) ±3 g/m²
- Covering coating Max. 5 mm
- Flat fabric for valve/bottom patch (2.5 – 5mm PP tapes)
- Fabric weight 60-80 g/m²
- 15% PE, 85% PP coating on both sides 20-30 g/m²
- Coating adhesion Min. 2.7 N/cm
- Width tolerance ±3 mm
- Weight tolerance (fabric with coating) ±3 g/m²
- Roll diameter 1,500 mm
- Core inside diameter 203.2 mm
- Unwinding diameter 1,000 mm
- Core inside diameter 203.2 mm
- Operating pressure: 6 – 7 bar
- Approx. air consumption 120 Nm³/h
