STARLINGER ADStar-KON 1001
Starlinger ADStar-KON 1001 – Valve Sack conversion machine
STARLINGER ADStar-KON 1001 – Valve Sack conversion machine is an advanced automatic bag conversion machine designed to manufacture valve sacks from woven polypropylene (PP) fabric.
These durable, high-quality sacks are widely used for cement, chemicals, grains, fertilizers, and other bulk materials.
Brand & Model: STARLINGER ADStar-KON 1001
Type: Valve Sack Conversion Machine
Application: Production of high-quality valve sacks from woven PP fabric
Size range:
- Sack width, double flat 350-600 mm
- Sack length 450-910 mm
- Bottom width (B > 160 mm only for open mouth sacks) 80-180 mm
- Bottom center distance 350-750 mm
- Cutting length of tubular fabric 530-1090 mm
Valve
- Cutting length 80-200 mm
- (pocket valve) (80-300 mm)
- Fabric width 170-330 mm
Cover patch:
- Cutting length 230-480 mm
- Fabric width 75-175 mm Section length 230-480 mm
Capacity: Production speed 85* sacks/min
Material specifications:
- Tubular fabric (2.5-5 mm PP tapes)
- Fabric weight 55-80 g/m²
- Coating of the outer sides 17-30 g/m² 15% PE, 85% PP
- Adhesion of coating min. 2.7 N/cm Width tolerance ±7 mm Weight tolerance ±3 g/m² (fabric + coating)
- Over coating max. 5 mm
- Outside diameter of the main fabric roll max. 1500 mm at the beginning of the processing min. 1000 mm
- Inside diameter of the core 203 mm
- Max. edge displacement (due to transverse motion unit): 15 mm
- Flat fabric for valve/cover patch
(2.5-5 mm PP tapes)
- Fabric weight 55-80 g/m²
- Bilateral coating 17-30 g/m² 15% PE, 85% PP
- Adhesion of coating min. 2.7 N/cm
- Width tolerance ±3 mm
- Weight tolerance ±3 g/m² (fabric + coating)
- Outside diameter of the fabric roll max. 1000 mm at the beginning of the processing min. 800 mm
- Inside diameter of the core 203 mm (8”) Inch
Power consumption: Connected load 105 kVA
MICRO-STAR (BILATERAL MICRO-PERFORATION) Used to insert pinholes into the tubular fabric at small intervals, to allow for better air permeability when an ad*star® bag is being filled. At the same time, the fine pinholes reduce dust emissions. Special pin rollers act upon the surface of the fabric and consequently on the powered backing roller behind it. The upper- and lower side of the tubular fabric can be perforated independently. In addition, perforation output can be modified at any time (even while the machine is running).
Contact us today for more details or to arrange an inspection!
