Feeding Conveyor Belt for WPL 1500 Shredder
Find similar machines
Feeding Conveyor Belt for WPL 1500 Shredder
Professional-grade feeding conveyor belt engineered for seamless material infeed into WPL 1500 shredders. Features a robust 1,400 mm belt width with 30° incline capability, 500 kg/m payload capacity, and SEW motor-driven performance for reliable recycling operations.
Key Specifications
- Idler Diameter: Ø 63.5 mm
- Drive Drum Diameter: Ø 416 mm
- Return Drum Diameter: Ø 400 mm
- Belt Type: Rubber belt with cleats
- Material Guide Height: 400 mm
Complete Specifications
| Belt Width | 1,400 mm |
| Useable Belt Width | 1,300 mm |
| Centre Distance | 9,500 mm |
| Incline Angle | 30° |
| Drop Height | 4,400 mm |
| Maximum Payload Per Meter | 500 kg |
| Motor Power | 7.5 KW |
| Motor Manufacturer | SEW |
| Motor Voltage | 400 Volt |
| Motor Frequency | 50 Hz |
| Motor Protection Rating | IP 54 |
| Drive Side | Right |
| Conveying Speed | 0.2 m/s |
| Belt Type | Rubber belt with cleats |
| Block Cleat Height | 40 mm |
| Block Cleat Distance | 1,000 mm |
| Idler Diameter | Ø 63.5 mm |
| Material Guide Height | 400 mm |
| Drive Drum Diameter | Ø 416 mm |
| Drive Drum Type | Rubberized |
| Return Drum Diameter | Ø 400 mm |
| Return Drum Type | Rubberized |
| Scraper Type | Plough scraper |
| Frame Construction | Solid square tube 70/50/4, welded |
| Support Adjustment | Height adjustable ±50 mm |
| Emergency Stop | Both sides |
| Casing Material | Sheet metal, removable by segments |
| Finish Color | RAL 7016 (anthracite grey) and RAL 2002 (blood orange) |
| Compatibility | WEIMA shredder connection |
| Compliance | EC Installation Declaration to Machinery Directive 2006/42/EC |
