ENGEL 3550-400 POWER
High-performance 400-ton clamping force injection moulding machine equipped with advanced CC200 control system and integrated 6-axis Kuka robot with 2,500mm radius. Features dual cooling circuits, thermal blankets for energy efficiency, and comprehensive automation capabilities for thermoplastic processing.
Key Specifications
- Robot Type: 6-axis Kuka
- Programmable Outputs: 4
- Screw Diameter: 90 mm
- Material Type: Thermoplastics
- Maximum Injection Speed: 529 cm³/s
Complete Specifications
| Clamping Force | 400 T |
| Material Type | Thermoplastics |
| Screw Diameter | 90 mm |
| L D Ratio | 22 |
| Max Injection Pressure | 1,600 bar |
| Maximum Injection Speed | 529 cm³/s |
| Vault Volume | 2,480 cm³ |
| Opening Stroke | 1,000 mm |
| Max Distance Between Platens | 1,450 mm |
| Ejection Stroke | 250 mm |
| Minimum Mold Thickness | 450 mm |
| Cooling Circuits Injection Side | 8 |
| Cooling Circuits Ejection Side | 8 |
| Control System | CC200 Control |
| Core Holders | 3 hydraulic + 1 electric |
| Hot Mould Chamber Zones | 4 |
| Programmable Inputs | 4 |
| Programmable Outputs | 4 |
| Robot Type | 6-axis Kuka |
| Robot Radius | 2,500 mm |
| Robot Control | KR C4 integrated control system |
| Features | Thermal blankets, Masterbatch interface, Euromap 67 robot interface, Frequency inverter |
| Operating Hours | 50,000 |
