DM PACKAGING TAURUS
Sanitary Masks production line
Sanitary masks production line tor produce FFP2 and FFP3 masks. DM PACKAGING TAURUS sanitary masks production machine with 1 sealing unit with possibility to insert the filter on both type of masks. Brand & Model: DM PACKAGING TAURUS (1 sealing unit) Features and process: Technical description of the system:- Machine control and management via PLC + 7” Elco HMI Touch Screen panel.
- Approximate system dimensions: L10,000 X D1,500 X H2,200mm
- Ultrasonic system welders
- Ultrasonic power: 1500KW Sirius.
- Axis management via brushless Schneider servomotor
- 1 sets of rotating devices for welding ear loops
- Production speed: approximately 2,500 masks/hour
- Weight: approximately 1,500 kg.
- Automatic counting function for pieces produced
- Possibility of inserting the filter or not for the production of both types of masks.
- System compliant with CE regulations
- Contact areas for stainless steel masks
- Electrical panel compliant with standards, with safety modules for managing guards
- Operator safety protections – in compliance with CE regulations
- Electrical voltage：AC 400V 50HZ THREE PHASE
- Power consumption: about 30A
- Effective power：about 15KW
- Product transport via shaped porters in non-toxic food-grade plastic material
- Loading pallet 180 links (1800 mm) complete with stainless steel top and sides AISI304.
- Cantilever reel holder
- Adjustable film conveyor
- Film hauling and welding with two pairs of cold and hot rollers
- Rotating jaws for transversal welding
- 3 Brush-less Schneider motors
- Machine management drives
- Axis control systems
- Motorized unloading belt
- Control panel composed of:
- 7” Touch Screen (99 recipe memory)
- Thermoregulators for electronic longitudinal and transversal roller temperatures
- Potentiometer to adjust the motor speed
- Start, Stop buttons
- Weight Kg. 450
- Installed Power (KW) 3
- Voltage (Volt) 220 monophase
- Packaging Length (mm) min. 80 – max 500
- Sealers Length (mm) 190
- Film Width (mm) 420
How do I find the price of this machine?
We are happy to provide you the price for the machine you’re interested in via email. Please use the contact form down below or email us at info@euro-machinery.com. Mention the machine reference number and one of our team members will reach out to you shortly.
Where is the machine located?
Most of our machines are located in Europe, but for specific details on this machine please contact us.
How do I buy a machine?
Send us an inquiry on the machine product page via the contact form and one of our sales managers will get in touch with you shortly. If you need help finding the right machine, please send us an email or call – we are happy to help you. Find more information about how to buy used machines down below.
How does transport work?
Transport is a case by case basis and depends on the size and distance a machine should travel. We work together with the buyer and seller to facilitate transport when a machine is being bought. We have many partners for transport and can help find a supplier to suit your needs.
