ASB NISSEI 650 EXHD Injection Molding Machine
| Brand | |
|---|---|
| Screw Diameter |
75 mm |
Find similar machines
UTECO GOLD – SOLD
ASB NISSEI 650 EXHD Injection Molding Machine
Turn-key 19-liter polycarbonate bottle production line built around the proven ASB NISSEI 650 EXHD injection molding machine. Includes a complete set of 19-liter polycarbonate bottle molds, ready for immediate high-volume production of premium-quality bottles.
Key Specifications
- Model: 650 EXHD
- Injection Capacity: 1060 cm³/shot
- Plasticizing Capacity: 331 kgf/H
- Total Heating Capacity: 57.3 kW
- Screw Diameter: 75 mm
Complete Specifications
| Brand | ASB NISSEI |
| Model | 650 EXHD |
| Material | Polycarbonate |
| Production | Complete set 19 lt polycarbonate bottle mold |
| Injection Unit | Injection Unit IU-110 | 35 oz X2 |
| Screw Diameter | 75 mm |
| Injection Capacity | 1060 cm³/shot |
| Injection Pressure | 1317 kgf/cm² |
| Plasticizing Capacity | 331 kgf/H |
| Screw Stroke | 240 mm |
| Screw Speed | 0-140 rpm |
| Clamping Force Upper | 51200 kgf |
| Clamping Force Lower | 58200 kgf |
| Stretch Blow Molding Station | Stretch & blow molding station |
| Stretch Stroke | 200 mm |
| Stretch Cylinder Diameter | 100 mm |
| Stretch Force | 775 kgf |
| Blow Core Stroke | 570 mm |
| Blow Core Cylinder Diameter | 125 mm |
| Blow Core Clamping Force | 1215 kgf |
| Blow Mold Clamping Force | 49500 kgf |
| Blow Mold Clamping Stroke | 460 mm |
| Bottom Mold Clamping Force | 11400 kgf |
| Bottom Mold Clamping Stroke | 60 mm |
| Bottle Ejector Stroke | 220 mm |
| Ejector Cylinder Diameter | 80 mm |
