Pimecsa ST-50 AR 3002,2 + support IBC

Liquid Agitator
Agitation degree: 23
Output speed: 287rpm
Vehicle flow: 11m³/min

Ref.: 8597 Categories: , ,

Pimecsa Solutions Agitator | support IBC

Intermediate Bulk Container (IBC) Liquid Agitator + Support with elements of 2ud. Ø 400 mm STIL turbine with 3 folding blades, in good working condition.


The supports of Agitators for IBC tanks are specifically designed for this type of tanks and consist of a bridge where the agitator is anchored and
sockets for the antlers of a mechanical bull or a stacker, which allows easy handling.
Agitator with medium-sized agitation elements with folding blades so that they can pass through the upper mouth of the tank.

Agitation degree: 23

Output speed: 287rpm

Vehicle flow: 11m³/min

Pimecsa Solutions Agitator – Connection: Stainless IBC bracket

Shaft: Stirring shaft Ø20mm and length 950mm

Elements: 2ud. Ø400mm STIL turbine with 3 folding blades

Start/Stop: Start-stop button panel with CETAC quick plug fully wired

Surface finish: Pickled

Equipment finish: RAL 5010 paint


  • Solids addition hopper
  • Liquids inlet
  • 10m of armored cable with CETAC connection in a safe area
  • EEx-i disconnector with CETAC integrated in the support
  • and more

Primecsa Liquid Agitator in good working condition as new! Contact us for more information.
