KUHNE Green Line 5-layer co-extruder

Extruders: 72 + 60 + 72 + 60 + 72 mm, L/D 30
Head: 5-Layer blown film Die head, fixed Die head
Die diameter: 350 mm; inserts for 1.5mm and 2.8mm

GET A PRICECONTACT YOUR SALES MANAGER

KUHNE Green Line 5-layer co-extruder

Brand & Model: KUHNE Green Line 5-layer co-extruder

Materials to be processed: LDPE, LLDPE, PP, HDPE, MDPE, EVA; thickness range 20-250 µ

Extruders: 72 + 60 + 72 + 60 + 72 mm, L/D 30

Head: 5-Layer blown film Die head, fixed Die head

Die diameter: 350 mm; inserts for 1.5mm and 2.8mm
IBC

Die Gap: 1.5 mm

Output: Up to 500 kg/hour depending on material formulation

Air ring: SmartLip MAXIMIZER TL 700

Take off: Rotating take off
Total film width 4000mm / lay-flat width 2000mm

Rewind:

  • Back-to-back contact gap winder
  • Automatic roll change with pneumatically operated cross cutting device
  • Reel diameter max 1200 mm
  • Winding width 2100 mm
  • Shafts 76.2mm/3” & 152.4mm/6”

Accessories:

  • Tower structure
  • Vacuum conveyor system, MOTAN, for 5 extruders
  • Gravimetric dosing system, OCTAGON
    ✓ 1 main and 4 secondary components for extruder A+C+E
    ✓ 1 main and 3 secondary components for extruder B+D
  • KUHNE extrusion control KEC, SIEMENS
  • Automatic thickness measurement, VenPad
  • Automatic width control
  • Motorized calibrating basket, Kdesign
    ✓ Diameter and height adjustment possible
    ✓ adjustment range 800-2500mm
  • Corona-treater, AFS
  • Web guide, BST
  • Gusseting boards
  • And more.

The KUHNE 5-layer co-extruder line is in great condition, please contact ask for more information.
